Supported Routers

Last updated: May 2023

Supported Routers

Recommended: Meraki Endpoints

You can add only supported Meraki MX models to use with Cisco dCloud. See more about Meraki in How Routers Work with Cisco dCloud.

Discover how to Troubleshoot Meraki Issues, Open Firewall Ports for Session Access, and explore Cisco Developer resources. Meraki LearningLabs, and Documentation.

The following Cisco router models, configurations, and Meraki endpoints have been tested by the Cisco dCloud Team for use with dCloud. All router models tested with dCloud are listed, including routers recommended for dCloud use and other tested models.

We recommend that the IOS versions for any user-provided router and integrated or external access points (APs) be the tested versions or newer. If you have problems using a newer IOS version, contact Cisco dCloud Support.

Table 1.    Supported Meraki MX Endpoints

Learn more from Get a Meraki MX Router for dCloud Use.

Router ModelTested Router IOS VersionTested AP IOS VersionExternal/Internet Port (Connect router to Internet)Switch Ports (Connect router to laptops, IP phones, VXC devices)
MX67MX16.16Not ApplicableInternet 12 - 5 (No PoE support)
MX67WMX16.16Not ApplicableInternet 12 - 5 (No PoE support)
MX68MX16.16Not ApplicableInternet 13 - 12 (PoE support)
MX68WMX16.16Not ApplicableInternet 13 - 12 (PoE support)

Questions?

Learn more from Get a Meraki MX Router for dCloud Use. For general questions, see Routers and Endpoints Recommended for dCloud Solutions and Frequently Asked Questions.

To get answers to your questions before/as you design your configuration  and demo strategy, you can contact dCloud Technical Leads, dCloud Support, or the Community Development Team for guidance.



Legacy Routers

Most legacy routers are on the Cisco End-of-Sale and End-of-Support list. Therefore, Cisco dCloud Support can be limited for legacy router models.

Legacy routers used with Cisco dCloud must support Cisco® Easy VPN to allow a dCloud session to connect to it automatically. At this time, routers running Cisco IOS XE do not support Easy VPN and cannot be used to connect endpoints to Cisco dCloud.

Table 1.    Supported Meraki MX Endpoints

Router ModelTested Router IOS VersionTested AP IOS VersionExternal/Internet Port (Connect router to Internet)Switch Ports (Connect router to laptops, IP phones, VXC devices)
MX67MX16.16Not ApplicableInternet 12 - 5 (No PoE support)
MX67WMX16.16Not ApplicableInternet 12 - 5 (No PoE support)
MX68MX16.16Not ApplicableInternet 13 - 12 (PoE support)
MX68WMX16.16Not ApplicableInternet 13 - 12 (PoE support)



Table 2.    Tested Router Models and Configurations for Cisco dCloud

Router ModelTested Router IOS Version / Release NotesTested AP IOS VersionExternal/Internet Port (Connect router to Internet)Switch Ports (Connect router to laptops, IP phones, VXC devices)
819c800-universalk9-mz.SPA.154-3.M9.bin Release NotesNot Applicable (AP in Unified mode)WAN GE 0FE LAN 0 - 3 (No PoE support)
829GWir800-universalk9-bundle.SPA.156-3.M.bin Release Notesap1g3-k9w7-mx.153-3.JCWAN GE 0 (SFP Port, GLC-T copper SFP Required)GE LAN 0 - 4 (POE support)
871c870-advipservicesk9-mz.151-4.M7.bin Release NotesNot ApplicableWAN FE 4FE LAN 0 - 3
881c880voice-universalk9-mz.153-2.T1.bin Release Notesap801-k9w7-mx.124-10b.JA3WAN FE 4FE LAN 0 - 3
89xc890-universalk9-mz.152-1.T1.bin Release Notesap801-k9w7-mx.124-21a.JA1WAN GE 0FE LAN 0 - 7
891Fc800-universalk9-mz.SPA.154-1.T1.bin Release NotesNot ApplicableWAN GE 8GE LAN 0 - 7
1811Wc181x-advipservicesk9-mz.151-3.T3.bin Release NotesNot ApplicableFE 0Switch 2 - 9
1861c1861-advipservicesk9-mz.151-3.T3.bin Release NotesNot ApplicableFE 0/0ACT 0 - 7
19xxc1900-universalk9-mz.SPA.152-2.T.bin Release Notesap801-k9w7-mx.124-21a.JA1GE 0/0(EHWIC) PoE 0 - 7
1921c1900-universalk9-mz.SPA.151-2.T5.bin Release NotesNot ApplicableGE 0/0(EHWIC) PoE 0 - 7
2911c2900-universalk9-mz.SPA.153-3.M3.bin Release NotesNot ApplicableGE 0/0(EHWIC) PoE 0 - 6
